As one of North America’s most popular vehicle manufacturers, it won’t surprise you that we offer the widest range of tuning and diagnostic support for Ford vehicles, especially for the Mustang lineup. From the ’99 Mustang SVT Cobra to the latest generation Mustang 5.0 and GT500, we have support for nearly every pony car on the road. Whether your Ford is powered by the EcoBoost, Coyote V8, Power Stroke Diesel, or one of their supercharged engines, we have the support you need to exceed your vehicle goals.

Our VCM Suite tuning software and MPVI3 devices give you the power to tune for more horsepower and torque, better fuel economy, or somewhere in between, and run extensive diagnostics with advanced data logging capabilities. With unique features such as an ECM-controlled transbrake for select 10R80-equipped vehicles, VCM Suite gives you new levels of access and programming capabilities for Ford applications. For qualified tuners, offer these same capabilities to your customers with RTD and Tune Delivery Network (TDN) support.

Ford tuning support include:

  • NEW Advanced Transbrake and Drive Mode Profiles (features) for 2020-2023 Ford Explorer ST 3.0L EcoBoost/10R60. See the user guide here.
  • NEW 21-22 F-150 2.7L & 3.5L EcoBoost V6, 3.5L PowerBoost Hybrid V6, and 5.0L V8 support (including Whipple supercharger support) via Ford MG1 PCM Service (required for tuning).
  • NEW F-Series Power Stroke 6.7 diesel support with MD1 ECM Upgrade Service (required for tuning).
  • NEW 2019-2022 Ford Focus 1.0L EcoBoost and Focus ST/RS 2.3L EcoBoost support.
  • Direct flash capabilities via MPVI3 and export to 3rd party devices.
  • Broad EcoBoost coverage, including 2.3, 2.7, and 3.5L engines.
  • Exclusive ECM-controlled and customizable Transbrake launch functionality on 5.0L GT and select EcoBoost Mustangs with 10-Speed Automatic.
  • First to market with support for the 10-speed automatic transmission (Ford 10R80).
  • Quickest flash times in the industry.
  • Broad support for 99-04 Mustang V8, plus almost all 2004-2020 Ford applications.
  • Support for all 6.0, 6.4, and 6.7 Power Stroke diesel trucks, including FICM support.
  • TDN support for all Ford applications. Learn more about TDN.

Complete list of supported Ford vehicles:

FORD
Year Model Type Single Vehicle Ford or Universal Credits
21 Bronco Sport 1.5/2.0 4
05-12 Crown Victoria 4.6 2
17-19 Ecosport 1.0 EcoBoost (MED17.0.7) (2) 2
07-19 Edge 3.5 (Except EcoBoost) 2
15-19 Edge Sport 2.7 EcoBoost 2
19-20 Edge 2.0 (2) 4
19-22 Edge ST (2) 4
05-11 Escape 2.3, 3.0 2
13-19 Escape 2.0 EcoBoost 2
99-03 E-Series Van 7.3 Power Stroke (Diesel) (2) 2
06-14 E-Series Van 4.6 (Except Diesel) 2
05-08 E-Series Van 5.4 2
12 E-Series Van 5.4 2
15 E-Series Van 6.8 2
16-19 Everest 2.2, 3.2 (2) 4
99-03 Excursion 7.3 Power Stroke (Diesel) 2
03-05 Excursion 6.0 Power Stroke (Diesel) (Including FICM support) 2
05-14 Expedition 5.4 2
15-19 Expedition 3.5 EcoBoost 2
20-21 Expedition 3.5 EcoBoost (2) 4
04-16 Explorer 4.0, 4.6, 3.5 2
13 Explorer 2.0 2
13-18 Explorer Sport 2
19 Explorer 3.7 2
20 Explorer 2.3 Ecoboost (2) 4
20 Explorer 3.3L (2) 4
20-23 Explorer ST 2.3 & 3.0 EcoBoost, 3.3 Hybrid (2) 4
03-07 F-250/F-350/F-450/F-550 6.0 Powerstroke (Diesel) 2
04-10 F-150 4.6 & 5.4 Triton V8 (Non-Heritage Editions) 2
04-10 F-250/F-350/F-450/F-550 5.4 Triton V8 2
08-10 F-250/F-350/F-450/F-550 6.4 Powerstroke (Diesel) tdn 2
10-14 F-150 V8 (Incl. SVT Raptor) 2
11-19 F-250/F-350/F-450/F-550 6.7 Powerstroke (Diesel) 4
11-20 F-150 3.5 EcoBoost 2
21-22 F-150 3.5 EcoBoost 4
13 F-150 3.7 V6 2
15-17 F-150 2.7 EcoBoost 2
15-17 F-150 3.5 Non EcoBoost 2
21-22 F-150 3.5 PowerBoost Hybrid V6 4
15-17 F-150 5.0 2
17-20 F-150 Raptor 3.5 EcoBoost 2
21-22 F-150 Raptor 3.5 EcoBoost 4
18-19 F-150 3.0 Power Stroke (Diesel) (2) 4
18-20 F-150 2.7 EcoBoost 4
21-22 F-150 2.7 EcoBoost 4
18-20 F-150 5.0 V8 4
21-23 F-150 5.0 V8 (2) 4
21-22 F-150 5.0 PowerBoost V8 (2) 4
99-03 F-250/F-350/F-450/F-550 7.3 Power Stroke (Diesel) 1
11-19 F-250 6.2 2
20-22 F-250/F-350 6.2 V8 (2) 4
20-21 F-250/F-350/F-450/F-550 6.7 Power Stroke (Diesel) (2) 4
20-22 F-250/F-350/F-450 7.3L Godzilla V8 (Equipped w/ 10R140) (2) 4
20-23 F-350/F-450/F-550 7.3 Godzilla V8 Cab and Chassis (Equipped w/ 6R140) (2) 4
16 F-550 6.8 V10 2
16-19 F-650/F-750 7.3 V8 4
02-14 Falcon BA, BF, FG, FGX, Territory models (Including A6 TCM support) 2
12-21 Fiesta 1.0 EcoBoost 2
13-17 Fiesta ST 1.6 EcoBoost 2
13-18 Fiesta ST 1.6 EcoBoost (non-USDM) (MED17.0.1) (2) 2
17-19 Fiesta 1.0 EcoBoost (MED17.0.7) (2) 2
18-20 Fiesta ST 1.5 EcoBoost (non-USDM) (TC-277) 2
22 Fiesta ST 1.5L (MK8.5) (TC-277) 2
05-07 Five Hundred 3.0 2
09-16 Flex (Except EcoBoost) 2
05 Focus 2.3 2
05 Focus ZX5 2.0 2
06-07 Focus ZX3 2.0 2
11-18 Focus 2.0L (N/A) 2
13-18 Focus ST 2.0 EcoBoost 2
16-18 Focus RS 2.3 EcoBoost 2
17-19 Focus 1.0 EcoBoost (MED17.0.7) (2) 2
18-19 Focus 1.5L (EU) (2) 4
19-22 Focus 1.0L Ecoboost (2) 4
19-22 Focus ST/RS 2.3L Ecoboost (2) 4
17-19 Ford GT 3.5 2
05-06 Ford GT 5.4 (2) 1
06-07 Freestar 2
05-07 Freestyle 3.0 2
13-20 Fusion 2.0L EcoBoost 2
17-18 Fusion Sport 2.7 2
13-18 Kuga 2.0 EcoBoost 2
22-23 Maverick 2.0 EcoBoost (2) 4
99 Mustang SVT Cobra 1
99-04 Mustang GT 4.6 1
00 Mustang Cobra R 5.4 1
01 Mustang Bullitt 4.6 1
01 Mustang Cobra 4.6 1
03-04 Mustang Cobra 4.6 1
03-04 Mustang Mach 1 4.6 2
05-15 Mustang 3.7, 4.0 2
05-17 Mustang 4.6, 5.0, 5.4, 5.8 2
15-17 Mustang 2.3 EcoBoost 2
16-17 Mustang 3.7 2
16-19 Mustang GT350/GT350R 5.2 2
18-22 Mustang 2.3 EcoBoost 4
18-22 Mustang 5.0 4
20-22 Mustang GT500 (2) 4
23 Mustang GT/Mach 1/Ecoboost (2) 4
21 Puma ST 2
07-11 Ranger 2.3, 3.0, 4.0 2
11-19 Ranger 2.2, 3.2 (2) 4
19-22 Ranger 2.3 (2) 4
07 Sport Trac 4.0 2
04-19 Taurus 3.0, 3.5, 3.5 EcoBoost 2
03-05 Thunderbird 2
15-19 Transit 3.7 2
15-19 Transit EcoBoost 3.5 2
16-18 Transit Connect 2.5 4V 4
16-19 Transit 2.0L TDCi (3) 2
16-19 Transit Connect 2.0L TDCi (3) 2
16-19 Transit Custom 2.0L TDCi (3) 2
20 Transit EcoBoost 3.5 (2) 4
FORD ADDITIONAL SUPPORTED CONTROLLERS
Year Model Type Single Vehicle Ford or Universal Credits
03-07 6.0L Powerstroke Fuel Injector Control Module (FICM) 2
05-07 F-Series 6.0L Power Stroke 5R110 Transmission Control Module (TCM) 2
08-10 F-Series 6.4L Powerstroke 5R110 Transmission Control Module (TCM) tdn 2
11-16 F-Series 6.7L Powerstroke 6R140 Transmission Control Module (TCM) tdn 2
17-19 F-Series 6.7L Powerstroke 6R140 Transmission Control Module (TCM) tdn 2
20-21 F-Series 6.7L PowerStroke 10R140 Transmission Control Module (TCM) 2
17-20 F-150 EcoBoost 3.5L 10R80 Transmission Control Module (TCM) 2
20-21 ZF6HP26 6-Speed Transmission Control Module (TCM) 2
16-18 Focus RS AWD Rear Drive Unit (RDU) 2
20-22  Shelby GT500 TCM (TR_C75) (2) 4
N/A 5.2L GT500 Predator Control Pack (PCM) (TC-298B) 4
N/A 7.3L Ford Performance Control Pack A10 (PCM) (TC-298B) 4
N/A 7.3L Ford Performance Control Pack (Manual Transmission) (PCM) (TC-298B) 4
FRPP
Year Model Type Single Vehicle Ford or Universal Credits
18 Mustang Cobra Jet (2) 2
2.0L EcoBoost Manual Transmission Control Pack (M-6017-20T) 2
2.3L EcoBoost Manual Transmission Control Pack (M-6017-23T) 2
3.5L EcoBoost Manual Transmission Control Pack (M-6017-35CNTRL) 2
4.6L 3V Manual Transmission Control Pack (M-6017-463V) 2
5.0L Coyote 5.0L Manual Transmission Control Pack (M-6017-A504VA) 2
5.0L Coyote 5.0L Manual Transmission Control Pack (M-6017-504V) 2
5.0L 2018 Coyote 5.0L Manual Transmission Control Pack (M-6017-M50B) 4
5.0L 2018 Coyote 5.0L Automatic Transmission Control Pack (M-6017-M50BA) 4
5.4L 4V Supercharged Manual Transmission Control Pack (M-6017-54SC) 2
LINCOLN
Year Model Type Single Vehicle Ford or Universal Credits
20-23 Aviator 3.0 (2) 4
17-19 Continental 3.0 2
03-05 LS 3.9 2
09-10 MKS 2
10-19 MKT (Except EcoBoost) 2
17 MKX Premier 3.7 V6 2
05-14 Navigator 5.4 2
19-21 Navigator 3.5 EcoBoost 2
05-12 Towncar 4.6 2
MERCURY
Year Model Type Single Vehicle Ford or Universal Credits
05-12 Grand Marquis 4.6 2
02-11 Mariner 2
04-10 Mountaineer 4.6 2
04-09 Sable 2
MPVI3 currently does not support EEC-V vehicles in any capacity.
Only MPVI2 and MPVI2+ devices support EEC-V vehicles (excluding data logging capabilities).

Vehicles that are only supported by MPVI2, MPVI2+, and MPVI3 interfaces are identified below by a (2) after the vehicle model type.

EMISSIONS DRIVE CYCLES IN VCM SCANNER

Our hardware and software are designed to bring vehicles into emissions compliance and maintain compliance over their lifetime. When tuning your Ford vehicle, take advantage of emission Drive Cycles tests in VCM Scanner (v4.13+), like Highway Fuel Economy (HWFE), SFTP-SC03, and select European Drive Cycles to ensure your compliance and test your vehicle’s fuel economy.

Highway Fuel Economy (HWFE) – Test your light-duty vehicle’s highway fuel economy rating.

SFTP-SC03 – Test your vehicle’s exhaust emissions and on-road fuel economy rating when using air conditioning (A/C).

European Drive Cycles – European tests for emissions and fuel consumption.

10R80 10-Speed Automatic Transmission Tuning

10 speed transmittion

Put the power to the pavement like you mean it with 10R80 transmission tuning support using VCM Suite (TCM requires separate licensing). Build out your transmission tunes with adjustable parameters like TCM RPM Limits, Shift Scheduling, Shift Timing, Shift Pressures, Torque Converter and more so you can take advantage of every horsepower.

Building your (exempt) racecar? We also offer Transbrake tuning support for 5.0L GT and select EcoBoost Mustangs. This special feature can be useful in drag/track applications to allow for better launches off the line but should be used with caution.

*The transbrake can cause stress to a vehicle’s drivetrain and should be used with extreme caution. Use at your own risk.

TFord Rear Drive Unit (RDU) Tuning

Ford Rear Drive Unit (RDU) Tuning

Stay cool with Rear Drive Unit (RDU) tuning support in VCM Suite (requires separate licensing). Adjust parameters like Soft Overtemperature, Hard Overtemperature, Max Line Pressure, and Oil Life Thresholds so you make more reliable power on and off the track.

No AWD dyno for testing? No problem. Utilize a special function in VCM Scanner allowing you to enable/disable AWD mode when you don’t have access to an AWD dyno. It’s as easy as opening VCM Scanner > Vehicle Controls & Special Functions > and selecting Enable or Disable.

THE LEGACY CONTINUES

Take control of your vehicle’s performance and reliability with the new MPVI3 interface by HP Tuners. Use MPVI3 and VCM Suite to data log, scan, read, and write to any supported Ford model.

Learn more about MPVI3

×
